PWM Malevolent Semi-Modular Analog Synthesizer (Brand New)

PWM Malevolent Semi-Modular Analog Synthesizer (Brand New)

Regular price $611.00
Regular price $679.00 Sale price $611.00
Sale Sold out
Tax included. Shipping calculated at checkout.

One absolutely wild semi-modular completely analogue mono synthesizer!

This thing sounds incredible. Super fat analog tone we all know and love, but in an ultra portable package with slim keys that make this synth a joy to play.

We particularly love the inbuilt overdrive circuit which makes leads crunchy and edgy and basses even bigger and more... malevolent?

The PWM Malevolent is absolutely feature packed and unparalleled at this price-point. Check this out:

  • Pure Analogue signal path designed by Future Sound Systems
    • Pure VCOs
    • 19 Outputs and 19 Inputs for 3.5mm mono jack cable patching
    • Normalised signal path for immediate sound Malevolence
    • Additional rear panel line out
    • Additional headphone out
  • 2 Voltage Controlled Oscillators
    • Saw / Triangle / Pulse outputs plus Mix for each oscillator
    • 1V/Oct pitch control input
    • Shape control / pulse width modulation input
    • 2x Frequency Modulation inputs
    • Coarse / Fine tune control
    • Shape mod amount control
    • FM1 and 2 mod amount controls
    • Shape control
    • Selectable waveforms for the mix output
    • Individual osc. level control
  • LFO (Low Frequency Oscillator)
    • Triangle / Square wave outputs
    • Rate control
  • 2x Envelopes
    • Individual ADSR controls for each envelope
    • Individual gate inputs
    • Individual envelope outputs
  •  Multi-mode 2 pole VCF (Voltage Controlled Filter)
    • Low pass / Band pass / High Pass individual inputs
    • 2x Frequency Modulation inputs with amount controls
    • Filter cutoff
    • Filter resonance
    • Low pass / Band pass / High Pass individual inputs
    • 2x Frequency Modulation inputs with amount controls
    • Filter cutoff
    • Filter resonance
  •  Mixer
    • Noise w/level control
    • Aux input w/level control
    • Noise w/level control
    • Aux input w/level control
  • VCA (Voltage Controlled Amplifier) with overdrive control
  • Compatible with Eurorack standard 1V/Oct gear
  • Monophonic and patchable allowing individual pitch control of each VCO and gate control of each envelope
  • USB bus-powered
  • MIDI In / Out
  • Headphone out
  • Line out
  • Analogue clock in & out
  • USB-MIDI to 1V/Oct CV & gate conversion
    • All pitch and gate control is fully analogue
    • Analogue clock In / Out
  • Multi-function Joystick control
    • Left / right for pitch bend
    • Performable portamento
    • Performable vibrato - in addition to the analogue LFO
    • Latching hold mode
  • Arpeggiator
    • 6 arpeggiator types
      • Up, Down, Up/Down 1, Up/Down 2, Played & Random
    • Auto clock sync
      • Detects analogue / MIDI or USB-MIDI clock and synchronises the arpeggiator automatically
    • Selectable sync rates when clock detected
    • Rate / sync control
    • Latch
    • 6 Octave range
    • Analogue / MIDI / USB-MIDI Clock output when arpeggiator is running
  • Keyboard Control
    • 32 Velocity-sensitive mini-keys
    • Octave shift +/- 4 octaves
    • Pitch output
    • Velocity output
    • Gate output
    • Local Off mode for DAW use
  • Includes:
    • 5 Patch cables
    • Power Supply (9V 600mA)
    • USB C lead
    • Getting Started Guide
